ASSET BEBO GREEN BRIDGE
®
Aesthetically pleasing, modular designs that compliment the surrounding environment.
![EPD Logo](https://static.wixstatic.com/media/fa2b02_20fc5bfd4025470992a62a044c05e700~mv2.png/v1/fill/w_249,h_86,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/Product-Banner-BEBO-cert-logo.png)
asset BEBO® Green Bridges minimise embodied carbon through simple modular construction. The concrete arch structures have also been designed with surrounding wildlife and ecosystems in mind.
![asset concrete logo](https://static.wixstatic.com/media/fa2b02_7ef7ca13da9740e9ac3f11416eeb45ee~mv2.png/v1/fill/w_380,h_86,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/Asset%20International%20Structures%20-%20Asset%20Concrete%20Logo%20(Text).png)
![Application Icons](https://static.wixstatic.com/media/fa2b02_f166b4b8f72b406789597b0278f3742a~mv2.png/v1/fill/w_400,h_343,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/Application%20Icons%20-%20BEBO%20Green%20Bridge.png)
SUITABLE APPLICATIONS:
Green
bridges
Wildlife
bridges
Pedestrian overbridges
Livestock underpasses
Rail
bridges
ASSET BEBO GREEN BRIDGE BENEFITS
®
![Product Feature Icons](https://static.wixstatic.com/media/fa2b02_0df1587c3b1f426390c572c3a6b9ecf4~mv2.png/v1/fill/w_400,h_343,al_c,q_85,usm_0.66_1.00_0.01,enc_auto/Feature%20Icons%20-%20BEBO%20Arch.png)
Aesthetically pleasing
Vertical
loads
Durable
On-site construction
Modular
Shapes
Concrete Arch
Span
PRODUCT FEATURES:
![Benefits Icon - BEBO Green Bridge.png](https://static.wixstatic.com/media/fa2b02_b8986054bace4bf6b1df33571595bb17~mv2.png/v1/fill/w_113,h_113,al_c,q_85,usm_0.66_1.00_0.01,blur_2,enc_auto/Benefits%20Icon%20-%20BEBO%20Green%20Bridge.png)
Reduced
driver's fatigue
Wildlife Connectivity
Green
Corridors
Lower Carbon Emissions
TYPES OF SYSTEM
USED & APPROVED BY:
-
Consultants
-
Public authorities
-
Local government
-
Property developers
-
House builders
-
Contractors in the road & rail sectors within the UK and Ireland
APPROVALS:
-
CAT2 sign-off
DESIGNED TO:
-
Compliant to the latest Eurocode standard
WORKING TO:
-
CDM Guidelines
-
FPC (Factory Production Control)
-
ISO 9001
ASSET BEBO CONCRETE ARCH STRUCTURE TYPES
®
![](https://static.wixstatic.com/media/fa2b02_e5f0cc2de74549b79d475ccf5645ac40~mv2.png/v1/fill/w_90,h_54,al_c,q_85,usm_0.66_1.00_0.01,blur_2,enc_auto/E-Series%20Box.png)
SPAN RANGE
3.7m (E12) up to 30m (E30mT).
SINGLE LEAF ARCH (E12 TO E48)
For spans up to 14.6m, a single arch element forms a complete arch ring.
TWIN LEAF ARCH (E15.5mT to E30mT)
For spans from 15.5m upwards, two elements form one arch ring.
OVERFILL HEIGHTS
The standard range of overfill above the arch crown is 0.6m (minimum) to 5.0m (maximum).
ASSET BEBO E-SERIES
®
![BEBO E-Series technical drawing](https://static.wixstatic.com/media/fa2b02_2c226c7eb5984585aac0be6f30cb1f54~mv2.jpg/v1/fill/w_103,h_56,al_c,q_80,usm_0.66_1.00_0.01,blur_2,enc_auto/E-Series-Image.jpg)
![](https://static.wixstatic.com/media/fa2b02_9ca020076eec44ceb2fd829b00f2541f~mv2.png/v1/fill/w_32,h_40,al_c,q_85,usm_0.66_1.00_0.01,blur_3,enc_auto/CLICK%20ICONS%20-%20FRP%20ICON_edited_edited.png)
CLICK image to enlarge
Contact us today for more detailed product information.
![](https://static.wixstatic.com/media/fa2b02_f12cf6b5569f48808a7640306c4e66d0~mv2.png/v1/fill/w_90,h_51,al_c,q_85,usm_0.66_1.00_0.01,blur_2,enc_auto/C-Series%20Box.png)
PAN RANGE
9.1m (C30T) up to 20.1m (C66T).
TWIN LEAF ARCH (C30T TO C66T)
For all spans, two arch elements form one complete arch ring.
OVERFILL HEIGHTS
The standard range of overfill above the arch crown is 0.6m (minimum) to 5.0m (maximum).
C-Series arches, however, can handle considerably higher overfills in excess of 10m.
ASSET BEBO C-SERIES
®
![BEBO C-Series technical drawing](https://static.wixstatic.com/media/fa2b02_e77e8ed982604aabb37041dff6548abe~mv2.jpg/v1/fill/w_95,h_51,al_c,q_80,usm_0.66_1.00_0.01,blur_2,enc_auto/C-Series-Image.jpg)
![](https://static.wixstatic.com/media/fa2b02_ac3ec81aa0d647fdb255026556117bb1~mv2.png/v1/fill/w_32,h_40,al_c,q_85,usm_0.66_1.00_0.01,blur_3,enc_auto/Download%20Icon%20(Brown).png)
CLICK image to enlarge
Contact us today for more detailed product information.
![](https://static.wixstatic.com/media/fa2b02_f2e5c78e98504d7ba452abacc5fda127~mv2.png/v1/fill/w_90,h_55,al_c,q_85,usm_0.66_1.00_0.01,blur_2,enc_auto/T-Series%20Box.png)
SPAN RANGE
10m to in excess of 35m.
SINGLE LEAF ARCH (T10M TO T12.5M)
For spans up to 12.5m, a single arch element forms a complete arch ring.
TWIN LEAF ARCH (T15mT TO T30mT)
For spans from 15m upwards, two elements form one arch ring.
OVERFILL HEIGHTS
The standard range of overfill above the arch crown is 0.6m (minimum) to 2.0m (maximum).
ASSET BEBO T-SERIES
®
![](https://static.wixstatic.com/media/fa2b02_4ddcfe6e25d046fe858a1214833a7ea3~mv2.png/v1/fill/w_32,h_40,al_c,q_85,usm_0.66_1.00_0.01,blur_3,enc_auto/Download%20Icon%20(Light%20Brown).png)
CLICK image to enlarge
![BEBO T-Series technical drawing](https://static.wixstatic.com/media/fa2b02_9b607ff4b1c24afeac40ac47f6af4420~mv2.jpg/v1/crop/x_0,y_435,w_7633,h_3277/fill/w_97,h_42,al_c,q_80,usm_0.66_1.00_0.01,blur_2,enc_auto/T-Series-Image.jpg)
Contact us today for more detailed product information.
